About small vtl

Types of small VTLs

A Vertical turret lathe (VTL) is one of the common types of lathes used in the metalworking industry for machining cylindrical parts and other shapes. Small VTLs are tabletop or floor-standing designs used for light-duty metal cutting and turning operations. They mainly have a power-assisted clamping mechanism to securely hold workpieces while an operator manually controls the feeding and releasing motions with the help of a feed lever.

Automatic tool-changing mechanisms use a form of ATCs (Automatic Tool Changings) to enable the machine to change its working tools automatically, and some designs come with as many as 12 working tools. An ATC usually recognizes a tool by its shape and size and has a certain algorithm to decide which tool to use for a certain job. In many cases, the tools will normally be already preset, which speeds up the process.

An automatic power switch will turn the machine on or off depending on the job at hand, and the job can either require the machine to be running continuously or just sporadically, such as in the case of an assembly line where the lathe may be doing the same operation on many pieces repeatedly or in a more custom environment where the lathe may be working on a single board several times in different locations.

A spindle servo can be used to control the speed of the lathe and the direction in which it turns. This is usually done on a small VTL through a digital control pad that allows the operator to set the exact parameters for the operation to a high degree of accuracy. A foot pedal or hand switch can also be used to control the speed and direction as it is more hands-on and can allow for better acceleration. The servo can also be programmed to carry out certain routines and functions automatically with the lathe working in a certain direction and carrying out a certain operation or speed.

Some small VTLs are further categorized into rotary and manual types. An operator spins the workpiece in a manual vertical lathe, whereas, in a rotary vertical lathe, the spindle rotates to move the tools against the workpiece. All VTLs share common components such as the bed, spindle, cutting tool, and tailstock.

Specifications and maintenance of small VTLS

The specifications of small vertical turning lathe machine may vary from one model to another. However, some features are commonly similar across all models.

  • Machining diameter and height

    Small VTLs have a machining diameter and height of between 300 to 600 mm. This means that they can easily work on small and medium-sized workpieces.

  • Control system

    A small VTL features any of the popular CNC control systems. This gives it automated and programmable machining ability. Therefore, it can produce workpieces with excellent precision and consistency.

  • Spindle speed

    The spindle speed of a small VTL can vary from 1,500 to 5,000 rpm. A higher spindle speed allows efficient machining of workpieces. This reduces processing time and improves productivity.

  • Power

    Small VTLs are designed for light to medium machining. Therefore, the motor power ranges from 3 to 15 kW. The torque generated is sufficient to carry out precise turning operations of different types of materials.

  • Indexing system

    The indexing system enables rotational positioning of workpieces. Some small VTLs have an automatic indexing system that improves machining efficiency and accuracy.

  • Tool holders

    Small VTLs have different types of tool holders. They include live tool holders, quick-change holders, and automatic tool holders. This allows for various machining operations such as turning, grooving, drilling, and threading.

Maintenance

To extend their lifespan and ensure better performance, it is important to maintain small vertical turning lathes regularly. The manufacturer provides a recommended maintenance schedule and routine. However, here are a few tips to help operators maintain the machine effectively.

  • Check the machine parts regularly. This inspection helps operators to identify any signs of wear, damage, or looseness of any part of the VTL. The parts should be repaired or replaced immediately.
  • Lubrication is essential for the moving parts of the VTL. The tool holders, rails, gear, bearings, and support blocks should be lubricated on a regular basis. The frequency of lubrication will depend on how often the machine operates. Operators should use the recommended lubricants and oil to enhance the machine's performance and extend its lifespan.
  • Clean and remove any dirt, debris, or coolant buildup on the machine parts frequently. A soft brush and a cleaning cloth can be used during the cleaning process. A separate dust blower can help remove dirt from hard-to-reach areas. Cleaning preserves the machining accuracy and ensures proper operation.
  • Operator manuals come with maintenance manuals for different vertical turning lathes. The manual indicates when and how to perform specific maintenance tasks. It also indicates the recommended replacement schedules for parts like filters and belts. Following the manual helps the machine to operate seamlessly and increases its lifespan.

Applications of small VTLs

Small VTLs may be small machines, but they have many uses in different industries. They can handle many things from pipe fittings to valve bodies and carbide tubes.

The most common use is for large workpieces with a central hole that need facing, boring, or threading. Such workpieces are found in the oil, chemical, power generation, aerospace, military, and metallurgical industries. These industries use the small vertical turning lathe machineto process large pipes, columns, discs, and other workpieces that have a central cavity.

Small VTLs can also machine workpieces with complex shapes when used with other tools. They can be combined with tool changers, clamping fixtures, and CNC systems for more outstanding automation. The automation allows the lathe to handle more complex machining tasks. When combined with other tools, the vertical lathe can also perform milling or drilling operations.

Another common use for the lathe is when it machines materials in high volumes. Some industries may need to process thousands of the same workpieces every day. The vertical spindles of the lathe make it suitable for disc-shaped materials requiring machining in large numbers. Its high-speed rotation reduces the machining time per unit.

Some features of small VTLs make them easy to use. CNC control allows the lathe to be operated programmably, reducing dependence on manual skills. Automatic loading and unloading means that workers do not have to stand by the machine all the time. The automation makes the machine more efficient and, in some cases, reduces the number of workers required to run an entire factory line.

The simplicity of design means that maintenance and spare parts are easy to find. Small vertical lathes can sometimes have modular parts so that entire sections can be replaced rather than breaking down an entire unit to discover the fault.

Another application of the vertical lathe machine is in the jewelry-making industry. Small jewelry VTLs can cut, drill, engrave, and groove precious metals like gold, silver, and platinum. Newer lathe models have CNC programming for intricate and detailed work with high precision. Jewelry vertical lathes can produce rings, pendants, necklaces, bracelets, and other components and parts of jewelry.

How to Choose Small VTLs

When choosing a small vertical tool lathe machine for purchase, buyers should consider the features of the VTLs to know how they affect the performance of the VTLs. They should also consider the applications of the small vertical VTL they intend to buy, as well as their specific needs and skill level.

The functionalities of a small vertical VTL can affect its performance. Consider a machine with a basic on/off switch rather than a simple or advanced control system with various settings. Look for options with a digital readout (DRO) for faster and more accurate machining with better productivity. Also, look at the cutting tools and workpiece clamping features. Some small vertical VTLs may have quick change tool posts or preset tool holders that make tool changes faster and easier. For efficiency, choose a machine with a manually operated or automatic clamping system.

Consider a small VTL with a capacity and size that can work with the types and sizes of workpieces. For example, workpieces with diameters or weights exceeding the capacity or rating of the lathe cannot be turned. The power requirements of VTLs with direct-drive or belt-drive motors can differ. A motor with low horsepower will have a limited speed range. However, a motor with a higher horsepower will offer a wider range of speeds and torque.

The VTL’s design, construction, and build quality can tell how durable and reliable the machine is. Also, consider its maintenance requirements and the availability of any replacement parts.

Invest in a reliable vertical lathe that will last longer. Machines with precision machining and tight tolerances have better performance and longevity. Also, look for a VTL with shock absorbers and proper bearings to reduce vibration. Vibration can affect the quality of the workpiece being turned.

The best way to choose a small vertical lathe is to familiarize oneself with the machine's operation. A simple training program or demonstration can help the buyer understand the main parts and functions of the VTL. Consider using the feedback from other users in the region to help in the final decision-making process.

Small vtl Q&A

Q1: What is the difference between a small VTL and a large VTL?

A1: The main difference between small and large VTLs is the size and capacity of the machine. Larger models can accommodate bigger workpieces, and they also have more powerful motors and larger tooling systems to handle heavier and larger parts.

Q2: What materials can a small VTL cut?

A2: Small VTLs can cut various materials, including metals such as steel, aluminum, brass, and titanium. Some small VTLs are also suitable for non-metal materials like plastics, composites, and ceramics.

Q3: What is the maximum cutting diameter and height of a small VTL?

A3: Depending on the design and specifications of different models, the maximum cutting diameter and height can vary. Generally, small VTLs have a maximum cutting diameter of over 500mm and a maximum height of about 400mm.

Q4: What is the power of a small VTL?

A4: The motor power of a small VTL generally is between 1.5kw and 4.5kw.
